Teupen 30T - Spider lift
Teupen Spider Lift - 30.0m Hybrid| Teupen 30T Electric
Arrow-left
Arrow-right

DSP300

Teupen 30T

Spider Lift – 30.0m Diesel

The Teupen 30T Spider lifts provides a working height of 30 m and a maximum of 15 m horizontal reach. The maximum lift capacity for this Teupen is 200 kg.

Rent this machine

Need help with rental?
Safety gear required
Technical data
Driving propulsion
Diesel
Working height
30,00 m
Outreach
15,00 m
Workload Capacity
200 kg
Own weight
4.225 kg
Platform dimensions (d x w)
1,20 x 0,80m
Transport dimensions (d x w x h)
7,20 x 1,58 x 1,98m
Max platform height
28,00 m
Max platform outreach
15,00 m
Up & over height
2,00 m
Maneuvering at height
No
Usage
Outdoor, Offroad
Lifting Propulsion
Electric
Diagram
Downloads

An upgrade in toughness and strength from the well proven

The Teupen Leo 30T spider lift offers working height of 30 m and it wide range of features can fulfill various requirements for indoor and outdoor operations. Its multi-position stabilizer system permits to automatically set up the machine in confined areas and on slopes.The powerful rubber track drive allows maneuvering the spider lift to the millimeter. It also allows to drive the lift through rough terrain and climb steep slopes. Manlift spider lifts are equipped with an electric motor which allow you to work silently and emission free to carry out indoor operations.

This bestselling model, with an outstanding versatility, is especially suited to serve in various indoor and outdoor applications. With the radio remote control the LEO30T is controlled from one spot – either in the platform or walking alongside the machine for the best overview while manoeuvring. On the control panel in the platform, an interactive display shows all available boom functions, safety information and allows error analysis. Safe positioning even with little space: The multi-level, multi-position stabiliser system permits to automatically set up the machine in confined areas and on slopes. It offers 3 different setup positions: Both sides wide, one side wide and one side narrow or both sides narrow. In terrain or over obstacles the stabilisers overcome a height difference of 1,20 m.
